Our General Purpose Mild Steel Welding Electrodes are designed for all-position welding of mild steels. They feature a smooth, stable arc with low spatter and excellent slag detachability. These electrodes are ideal for both professionals and hobbyists, ensuring high-quality welds with fine bead appearance.
Suitable for joining structural steels, light gauge sheet metals, and general fabrication work. The electrodes provide deep penetration and reliable x-ray quality welds, making them a versatile choice for a wide range of industrial and maintenance applications.
Key Features
- • Smooth and stable arc
- • Low spatter and easy slag removal
- • All-position welding including vertical-down
- • Excellent bead appearance
- • Radiographic quality welds
Technical Specifications
| Classification | AWS A5.1 E6013 / E7018 |
| Tensile Strength | 460 - 550 N/mm² |
| Yield Strength | > 380 N/mm² |
| Elongation | > 22% |
| Current Type | AC / DC+ |
Available Grades
60106011601260136013S6013SS60187010G701670187018-A17018-G7018-A1 H4R7018S7018S (SP) NACE7018S H4R70248018 C18018 C28018 C38018-B28018-B68018-B88018-D38018G8018W29015-B919018-B39018-G9018-G SPL10018 D210018-G11018-G11018M12018GCUT 300
Sizes & Diameters
2.50mm x 350mm3.15mm x 350mm/450mm4.00mm x 450mm5.00mm x 450mm
Packaging Options
- 2.5kg / 5kg Packets
- 20kg Master Carton
Common Applications
Structural fabrication
General repair and maintenance
Automobile bodies
Agricultural implements
Light gauge steel welding
Shipbuilding and storage tanks
